introduction
Turning Electric Actuator Cylinder (LOE80) is a light-load electric cylinder designed for precise rotary-to-linear motion control. It offers high-speed response and stable accuracy for industrial automation systems.
|
Motor Power (W) |
1000W (3000rpm) |
1000W (2000rpm) |
1500W (3000rpm) |
1500W (2000rpm) |
||||
|
Rated torque N. m |
3.18 |
4.77 |
4.77 |
7.16 |
||||
|
Driving mode |
Ball screw C7 conversion/ball screw C5 grinding (default C7) |
|||||||
|
Repeat positioning accuracy (mm) |
±0.02/±0.01 |
|||||||
|
Screw Lead (mm) |
5 |
10 |
5 |
10 |
5 |
10 |
5 |
10 |
|
Max speed (mm/sec) |
250 (1: 1) 83 (3: 1) |
500 (1: 1) 167 (3: 1) 125 (4: 1) 100 (5: 1) 83 (6: 1) |
167 (1: 1) |
333 (1: 1) 83 (4: 1) |
250 (1: 1) |
500 (1: 1) 167 (3: 1) 125 (4: 1) |
167 (1: 1) |
333 (1: 1) 111 (3: 1) |
|
Rated thrust (N) |
3395 (1: 1) 10185 (3: 1) |
1697 (1: 1) 5091 (3: 1) 6788 (4: 1) 8485 (5: 1) 10182 (6: 1) |
5092 (1: 1) |
2546 (1: 1) 7638 (3: 1) 10184 (4: 1) |
5092 (1: 1) |
2546 (1: 1) 7638 (3: 1) 10184 (4: 1) |
7644 (1: 1) |
3822 (1: 1) 11466 (3: 1) |
|
Effective stroke (mm) |
10-1200 |
|||||||
|
Sensor |
Electronic magnetic switch*3 |
|||||||
|
Motor Power (W) |
2000W(3000rpm) |
2000W(2000rpm) |
3000W(3000rpm) |
3000W(2000rpm) |
||||
|
Rated torque N. m |
6.37 |
9.55 |
9.55 |
14.32 |
||||
|
Driving mode |
Ball screw C7 conversion/ball screw C5 grinding (default C7) |
|||||||
|
Repeat positioning accuracy (mm) |
±0.02/±0.01 |
|||||||
|
Screw Lead (mm) |
5 |
10 |
5 |
10 |
5 |
10 |
5 |
10 |
|
Max speed (mm/sec) |
250 (1: 1) |
500 (1: 1) 167 (3: 1) |
167 (1: 1) |
333 (1: 1) |
250 (1: 1) |
500 (1: 1) |
500 (1: 1) |
|
|
Rated thrust (N) |
6800 (1: 1) |
3400 (1: 1) 10200 (3: 1) |
10196 (1: 1) |
5098 (1: 1) |
10196 (1: 1) |
5098 (1: 1) |
7644 (1: 1) |
|
|
Effective stroke (mm) |
10-1200 |
|||||||
|
Sensor |
Electronic magnetic switch*3 |
|||||||
features
Space-Saving Structure
The motor is mounted in parallel with the cylinder body and driven via a timing belt system, reducing axial length by up to 40–50% compared with direct-drive layouts.
Lightweight yet Rigid Body
The 80mm aluminum alloy barrel provides a balance of rigidity and low inertia, making the actuator suitable for high-cycle light-load operations.
High Precision
Equipped with C7 standard ball screws (C5 optional), the system achieves stable closed-loop control and repeatability up to ±0.01–±0.02 mm.
Energy Efficiency
Mechanical transmission efficiency exceeds 90%, eliminating compressed air losses found in pneumatic systems and enabling lower long-term operating energy consumption.
Low Maintenance
Preloaded mechanical structure and low-friction guidance reduce wear, supporting continuous industrial operation with minimal maintenance.
LIND Standard installation method and size diagram
CB: Rear double pin ears
CA: Rear single sales ear
FB: Rear bottom plater
TC: Rear ear axle seat
LA: Horizontal bearing seat
FG: Front flange with guide postt
FA: Front flange
FTC: Front ear axle seat
J: Frontjoint bearing
Y: Y-shaped hinge
SP: pressure sensor
applications
Designed for light-load applications and space-constrained installations, the LOE80 is widely used in:
- Automotive Manufacturing: Positioning of small components, interior assembly assistance, and precision part pushing.
- Light Automation Systems: Light workpiece handling, fixture actuation, precision sorting, and pushing tasks in small-scale automation equipment.
- 3C / Electronics Manufacturing: Precision alignment of small modules, light-duty pushing of electronic components, and display module assembly.
- Industrial Equipment: Auxiliary loading and unloading in small injection molding machines, compact machine tools, and packaging machinery.
- Custom Machinery: Precision pressing systems, miniature testing platforms, calibration equipment, and various space-restricted light-duty automation applications.
why choose us
Taiwan-based Technology with Intelligent Manufacturing in Wuxi
With over 30 years of experience in linear motion system development, the product combines Taiwan-developed engineering with advanced manufacturing in Wuxi. Key components are strictly selected to ensure stable mass production, consistent quality, and short lead times.
Flexible Integration for Multiple Applications
Standard configurations cover mainstream industrial requirements, while customization is available for stroke, thrust, mounting methods, motor orientation, and protection levels, enabling easy system integration.
FAQ
Q1: Can it replace pneumatic cylinders?
A: Yes. It replaces pneumatic systems in precision-driven applications, offering better controllability, repeatable positioning (±0.01–±0.02 mm), and reduced maintenance requirements.
Q2: What motors are compatible with the system?
A: It is compatible with mainstream servo/stepper motors and can be integrated with different drive configurations depending on required speed, force, and stroke setup.
Q3: What are the main structural advantages?
A: The aluminum alloy body provides lightweight design, improved thermal stability, and high rigidity, making it suitable for high-cycle industrial operation.
Q4: Is customization available for OEM projects?
A: Yes. Stroke length, mounting structure, motor interface, and control configuration can be customized for OEM/ODM integration into automated machinery.
