Introduction
The LOE16 Mini Direct-Drive Electric Cylinder is a compact precision actuator designed for small-scale automation, accurate positioning, and space-limited equipment integration.
Featuring a direct-drive structure, precision screw transmission, and flexible installation design, the LOE16 provides fast response, stable motion, and reliable performance for various industrial automation applications.
Its compact structure makes it suitable for robotic systems, testing equipment, precision assembly machines, and other applications requiring efficient linear motion.
Key Features of LOE16 Mini Electric Cylinder
• Fast Linear Response
The LOE16 adopts a direct-drive structure to achieve quick response and smooth linear movement.
It is designed for applications requiring fast positioning and efficient motion control.
• Compact and Flexible Installation
The compact structure allows easy integration into equipment with limited installation space.
The flexible layout design provides more possibilities for machine integration.
• Lightweight Aluminum Structure
The lightweight aluminum body reduces overall equipment weight while maintaining sufficient rigidity and mechanical stability.
This makes the LOE16 suitable for compact automation systems.
• High-Precision Linear Motion
The precision screw transmission provides accurate positioning and stable repeatability for demanding automation applications.
• Low Noise and Smooth Operation
The optimized mechanical structure reduces vibration and operating noise, making it suitable for precision equipment and noise-sensitive environments.
Why Ball Screw Instead of Lead Screw?
Ball screw technology provides advantages in efficiency, accuracy, and service life compared with traditional lead screw systems.
• Higher Accuracy
The rolling contact structure reduces friction and mechanical loss, improving positioning accuracy and repeatability.
•Better Efficiency
Lower friction helps reduce energy loss and heat generation during continuous operation.
•Longer Service Life
Reduced wear improves durability and reliability for long-term industrial applications.
Why Direct Drive?
The LOE16 adopts a direct-drive structure to simplify the transmission system.
• Reduced Mechanical Components
The motor directly drives the screw mechanism, eliminating additional transmission parts such as belts or couplings.
• Higher Reliability
Fewer mechanical components reduce potential failure points and maintenance requirements.
• Compact Integration
The direct-drive design helps achieve a smaller actuator size for compact equipment.
Why Fold-back Design?
The fold-back design provides a more compact installation solution.
•Space Saving
The optimized motor arrangement reduces the overall installation length.
•Flexible Equipment Integration
It allows easier installation in machines with limited space.
•Stable Performance
The compact design maintains rigidity and reliable positioning accuracy.
Technical Specifications
|
Motor Power (W) |
28 steps |
28 steps |
|
Driving mode |
C7 |
|
|
Repeat positioning accuracy (mm) |
±0.02/±0.01 |
|
|
Screw Lead (mm) |
2.5 |
2.5 |
|
Max speed (mm/sec) |
25 |
25 |
|
Rated thrust (N) |
149 |
200 |
|
Effective stroke (mm) |
2-200 |
|
|
Sensor |
Solenoid switch*3 |
|
This electric cylinder requires a 28 step stepper motor, a screw lead of 2.5mm, a maximum speed of 25mm/s, and an effective stroke of 2-200mm.
Customization Options
The LOE16 Mini Electric Cylinder can be customized according to different application requirements.
Available options include:
• Stroke Length Customization
Different stroke lengths can be provided based on equipment requirements.
•Motor Configuration
Motor specifications can be adjusted according to speed, torque, and control requirements.
• Mounting Interface
Customized mounting solutions are available for easier machine integration.
• Cable and Connector Options
Cable direction and connector types can be customized.
• Control Compatibility
The actuator can be adapted to different control systems.
Applications
Why Choose us
Efficient Delivery
Modular inventory and full-process manufacturing ensure standard orders ship within 10 days.
Integrated Production
In-house machining and assembly ensure quality control across every production stage.
Engineering Support
Direct access to technical experts for rapid model selection and integration guidance.
R&D Strength
A portfolio of 40+ patents provides proven technical solutions for long-term stability.
Gates Quality Belt
FAQ
Q1: What is the delivery time for standard orders?
A: Standard models are shipped within 10 days of order confirmation.
Q2: Can the thrust and speed be adjusted?
A: Yes, we can customize the screw lead and motor steps to meet your specific load requirements.
Q3: How is travel safety managed?
A: Each unit comes standard with three magnetic switches for precise end-of-stroke detection.
Q4: Is each unit tested before shipping?
A: Yes, every cylinder undergoes laser alignment and torque calibration to ensure spec compliance.
Q5：Can the LOE16 electric cylinder be customized?
A：Yes. Stroke length, motor configuration, mounting interface, and control options can be customized according to application requirements.
Q6：What applications are suitable for LOE16?
A：The LOE16 is designed for compact automation equipment requiring fast response, precise positioning, and reliable linear motion.
