Industrial Compact Electric Linear Actuator | High-Precision Mini Electric Cylinder High Power Density in a Miniature Profile – The Ideal Pneumatic Replacement
Designed for automation environments where installation space is at a premium, our Compact Electric Linear Actuator series combines a highly miniaturized structural design with high thrust and industrial-grade durability. By reducing the overall footprint by up to 40% compared to standard electric cylinders, it provides design engineers with maximum flexibility without sacrificing load capacity or positioning accuracy.
Technical Specifications
|
Technical Parameter |
Specification (Fully Customizable) |
|
Input Voltage |
12V / 24V / 48V DC, 110V / 220V AC |
|
Max. Dynamic Thrust |
Up to 5,000 N (Depending on speed and screw pitch) |
|
Max. Static Holding Force |
Up to 10,000 N (Self-locking capable) |
|
Stroke Range |
10 mm - 500 mm (Customized to precise application) |
|
Max. Linear Speed |
Up to 50 mm/s |
|
Repeat Positioning Accuracy |
Ball Screw: ±0.02 mm | Lead Screw: ±0.05 mm |
|
Backlash |
≤ 0.03 mm (For high-precision models) |
|
Duty Cycle |
20% (Standard) up to 100% (Continuous Servo Control) |
|
IP Protection Rating |
IP54 / IP65 / IP66 / IP67 / IP69K (Optional) |
|
Operating Temperature |
-20°C to +65°C (Low-temp options available) |
|
Feedback Signal |
Encoder, Hall Sensor, Potentiometer, Internal Limit Switches |
Core Advantages & Product Features
Ultra-Compact Design (Space-Saving 40%)
Minimized inline or parallel motor configurations deliver a high power-to-weight ratio. It is the perfect fit for tight control cabinets, micro-mechanisms, and embedded robotic arms.
Precision Motion Control
Optimized ball screw and anti-backlash lead screw technologies provide sub-millimeter positioning accuracy. Replace erratic pneumatic strokes with smart, programmable linear motions.
Heavy-Duty & Rugged Build
Hard-anodized aluminum alloy housing and chrome-plated stainless steel extension rods ensure maximum rigidity and a service life exceeding 100,000+ cycles under full rated load.
100% Maintenance-Free
Factory-sealed lubrication ensures smooth, long-term operation. Eliminate the ongoing costs of air line maintenance or hydraulic fluid replacement.
Industrial Applications
Automated Factory Production
Multi-axis alignment systems, smart sorting gates, high-speed clamping devices, and precise pick-and-place grippers.
Medical & Biopharm Equipment
Lab automation pipetting systems, precision fluid dosing, medical imaging scanner adjustments, and ergonomic hospital furniture.
Aerospace & UAV Systems:
Throttle actuators, electronic valve controls, and drone camera gimbal stabilization inside compact cabins.
Lithium Battery & Semiconductor Manufacturing
Delicate material handling and precision assembly where oil and dust contamination must be strictly avoided.
Quality Assurance & Factory Verification
Our 4-Step Strict Inspection Process
Incoming Material Testing (IQC): Hardness, tolerance, and dimension checks on all incoming ball screws, bearings, and alloy housings.
Acoustic & Vibration Analysis: Every cylinder must maintain a smooth, ultra-quiet noise level below 50 dB during full stroke operational testing.
Waterproof Submersion Test: Rigorous verification of IP65/IP66 enclosures to safeguard internal electronics against dust and fluid ingress.
Full Load Lifetime Simulation: Random batch spot-testing under maximum rated load to guarantee performance consistency over time.
International Standards & Certifications
Our manufacturing facilities operate strictly under the ISO9001:2015 quality management framework.
All product series are fully certified with CE and RoHS, meeting strict international market access standards.
FAQ
Q: Can your compact linear actuator handle washdown or marine environments?
A: Yes. We can customize the actuator with SUS316 stainless steel rods, specialized anti-corrosion coatings, and up to IP67/IP69K protection ratings to easily withstand high-pressure water jets and salt spray.
Q: Do you support third-party motor integration (e.g., Panasonic, Siemens, Beckhoff)?
A: Absolutely. We design and manufacture customized motor adapter flanges and inline/parallel coupling housings to seamlessly fit your existing servo or stepper motor brands.
Q: What is your standard lead time for customized B2B orders?
A: Engineering samples and standard prototypes take 7-10 working days. For batch B2B customized orders, lead times generally range between 3-4 weeks depending on material availability and configuration requirements.
